The new SCHNEEBERGER absolute measuring system is another step into Industrial 4.0 linear bearings. 3 out of 5 Interfaces can be used simultaneously: BiSS/SSI, ABZ, UVW, SPI, analog Sin/Cos. Available from the smallest linear miniature guide MINIRAIL Size 5.
To receive a quote please fill in this form below. One of our sales representatives is glad to help you.
Scale lasered directly onto guide rail
MINISAM is an All-in-One solution and the smallest integrable measuring system for miniature guides. It is a Plug and Play system that is ready for use without the need for additional settings or adjustments.
The SAM measuring system offers five interface options: BiSS/SSI, ABZ, UVW, SPI, and analog Sin/Cos interfaces.
The SAM measuring system operates optically. A central illumination LED sensor and two lensless optical encoder windows detect the absolute position using a Pseudo-Random Code (PRC). Additionally, an incremental encoder is used for the interpolation of high-resolution position data.
The SAM measuring system can be integrated into all MINIRAIL sizes and carriage types, ranging from size 5 to 42.
The SAM system can either be connected via a flexprint to a connection board or directly to a controller. The flexprint can be customized by the customer. Depending on the application, the customer can decide whether a connection board is needed or not.
MINISAM is an All-in-One solution and the smallest integrable measuring system for miniature guides. It is a Plug and Play system that is ready for use without the need for additional settings or adjustments.
The SAM measuring system offers five interface options: BiSS/SSI, ABZ, UVW, SPI, and analog Sin/Cos interfaces.
The SAM measuring system operates optically. A central illumination LED sensor and two lensless optical encoder windows detect the absolute position using a Pseudo-Random Code (PRC). Additionally, an incremental encoder is used for the interpolation of high-resolution position data.
The SAM measuring system can be integrated into all MINIRAIL sizes and carriage types, ranging from size 5 to 42.
The SAM system can either be connected via a flexprint to a connection board or directly to a controller. The flexprint can be customized by the customer. Depending on the application, the customer can decide whether a connection board is needed or not.
