ミニチュアガイドウェイ、MINIRAIL、マイクロ無摩擦テーブル、MINISLIDE、および統合型距離測定システム、MINISCALE PLUSは、精度の高さ、堅牢性、多様性で非常に効果の高い製品であり、作業プロセスにおいて高速度と加速を行うために開発されました。
この新しく革新的な特許技術により、最大3 m / sの速度と最大250 m / s2の加速度に対応し、高精度で完璧な走行性能を保証します。
最高 4 つのキャリッジサイズと組み合わせることができる 8 種類のレール幅をご用意しています。
ショートキャリッジバージョン (注文コード MNNS)。 制限のある設置スペースに最適
ショートキャリッジを使用した場合のお客様にとっての利点：
Lifetime lubrication refers to a one-time filling of lubricant at the friction points, which does not need to be renewed or replaced throughout the product’s lifespan. SCHNEEBERGER has developed and patented the innovative LUBE-S system for this purpose.
LUBE-S provides maintenance-free operation for up to 20,000 km under normal conditions. The lubricant is directly applied to the balls in the load zone without affecting the carriage length or maximum stroke. This significantly reduces maintenance costs and lowers lubricant consumption, making it more environmentally friendly.
LUBE-S is a sophisticated lubricant reservoir that, via capillary action, dispenses lubricant to the balls located in the load zone. The system is fully integrated into the carriage and ensures reliable lubrication even in applications with short strokes.
LUBE-S can be used in almost all applications, but special applications such as vacuum and cleanroom environments are not suitable for the LUBE-S system.
MINIRAIL guideways excel in high precision and durability. Their design ensures high process reliability and allows for speeds of up to 5 m/s and accelerations of up to 300 m/s².
MINIRAIL rails come in standard widths of 7, 9, 12, and 15, as well as wide sizes of 14, 18, 24, and 42. The carriages are available in four lengths: MNNS (short), MNN (standard), MNNL (long), and MNNXL (extra-long).
Yes, MINIRAIL carriages are designed to be fully interchangeable with one another at any time. This unit carriage system simplifies inventory management and significantly reduces maintenance effort.
Lifetime lubrication refers to a one-time filling of lubricant at the friction points, which does not need to be renewed or replaced throughout the product’s lifespan. SCHNEEBERGER has developed and patented the innovative LUBE-S system for this purpose.
LUBE-S provides maintenance-free operation for up to 20,000 km under normal conditions. The lubricant is directly applied to the balls in the load zone without affecting the carriage length or maximum stroke. This significantly reduces maintenance costs and lowers lubricant consumption, making it more environmentally friendly.
LUBE-S is a sophisticated lubricant reservoir that, via capillary action, dispenses lubricant to the balls located in the load zone. The system is fully integrated into the carriage and ensures reliable lubrication even in applications with short strokes.
LUBE-S can be used in almost all applications, but special applications such as vacuum and cleanroom environments are not suitable for the LUBE-S system.
MINIRAIL guideways excel in high precision and durability. Their design ensures high process reliability and allows for speeds of up to 5 m/s and accelerations of up to 300 m/s².
MINIRAIL rails come in standard widths of 7, 9, 12, and 15, as well as wide sizes of 14, 18, 24, and 42. The carriages are available in four lengths: MNNS (short), MNN (standard), MNNL (long), and MNNXL (extra-long).
Yes, MINIRAIL carriages are designed to be fully interchangeable with one another at any time. This unit carriage system simplifies inventory management and significantly reduces maintenance effort.
SCHNEEBERGER MONORAIL and MINIRAIL profile guideways - limited quantity, easy ordering, quick delivery
| タイプ | ||||
| レール幅 (mm) | キャリッジ | バージョン | L | B |
| MNN 5 | MNN 5 | 標準 | 19.8 | 12 |
| MN 7 | MNNS 7 | ショート | 18.6 | 17 |
| MNN 7 | 標準 | 24.6 | 17 | |
| MNNL 7 | ロング | 32.1 | 17 | |
| MNNXL 7 | エクストラロング | 41.1 | 17 | |
| MN 9 | MNNS 9 | ショート | 22 | 20 |
| MNN 9 | 標準 | 32 | 20 | |
| MNNL 9 | ロング | 40 | 20 | |
| MNNXL 9 | エクストラロング | 50 | 20 | |
| MN 12 | MNNS 12 | ショート | 23.9 | 27 |
| MNN 12 | 標準 | 36.4 | 27 | |
| MNNL 12 | ロング | 46.4 | 27 | |
| MNNXL 12 | エクストラロング | 58.9 | 27 | |
| MN 15 | MNNS 15 | ショート | 31.7 | 32 |
| MNN 15 | 標準 | 43.7 | 32 | |
| MNNL 15 | ロング | 58.7 | 32 | |
| MNNXL 15 | エクストラロング | 73.7 | 32 | |
| MN 14 | MNN 14 | 標準 | 32.1 | 25 |
| MNNL 14 | ロング | 41.1 | 25 | |
| MN 18 | MNN 18 | 標準 | 40 | 30 |
| MNNL 18 | ロング | 50 | 30 | |
| MN 24 | MNN 24 | 標準 | 46.4 | 40 |
| MNNL 24 | ロング | 58.9 | 40 | |
| MN 42 | MNN 42 | 標準 | 55.7 | 60 |
| MNNL 42 | ロング | 73.7 | 60 | |
ミニレール – 最高加速度 30Gと最高 速度5 m/s を保証。最高の信頼性 キャリッジ内に完全に格納された循環経路
選択したサイズは構成できます。またすべてのコンマ データ形式で利用できます。適切なサイズの組み合わせをクリックしてダウンロードを開始してください。
ダウンロードを開始し、関連のサイズの組み合わせをクリックします。
以下のリンクをクリックすると、自動的にCADENASに移動します。
