As part of the further expansion of the SCHNEEBERGER Group, an additional site was founded in Poland. The new company SCHNEEBERGER Components Poland (SPO) officially started on November 19, 2020 and has already commenced operations, producing precision parts for the entire Group. This means that the production footprint defined as part of the long-term strategy development is being consistently implemented and further developed. Stefan Hantke (CEO SCHNEEBERGER Group): "With this measure, we have once again ensured that we actively support the growth of our customers in the long term. We are very pleased that we were able to win Mr. Boguslaw Czarkowski as Managing Director for this new company, a very experienced linear technology specialist with pronounced production expertise." Would you like to learn more? Then contact us. We look forward to hearing from you and working with you to develop the best solutions for you.

The precision and robustness of the MINISCALE PLUS optical distance measuring system is impressive. The product was developed for tight spaces as well as high speeds and increases in speed in the work process in conjunction with  high measuring accuracy. It is used in different high-tech sectors, such as in various medical technology and biotechnology applications. The MINISCALE PLUS is based on the MINIRAIL profile linear guideway and combines the characteristics of a linear encoder with those of a miniature profile linear guideway. The innovative embedding of ball recirculation in the carriage allows speeds of up to 5 m/s and increases of speed of up to 300 m/s2. With the combination of an integrated MINISCALE PLUS distance measuring system, the “Guide” and “Measurement” functions are offered on a single rail. MINISCALE PLUS therefore makes a significant contribution to a reduced TCO (total cost of ownership), as only one component needs to be ordered, stored, installed and…

SCHNEEBERGER is always ready to help when the know-how for developing a positioning system is not available to the customer, when such a development lies outside their core competency or when in-house development is not possible due to capacity restraints. Customers thus benefit from SCHNEEBERGER’S experience and expertise as a designer and developer of positioning systems for a wide variety of applications in the semiconductor industry, in medical technology and biotechnology, in the optics industry and in microscopy. SCHNEEBERGER’S systems are fundamentally developed and manufactured together with and for our customers. They are the epitome of extremely accurate and reliable linear technology for high-end machines and devices. Positioning accuracy, speed, vacuum suitability and the perfect fine-tuning of all individual components are part of the axiomatic setup.  This is how, for example, the depicted Open Frame XY positioning system was created. Our customer wanted a completely…

When space constraints and performance are required for distance measurement, MONORAIL AMS is the answer. SCHNEEBERGER integrates a measuring head and scale onto its MONORAIL profile linear guideways. In brief: Integrated AMS distance measuring systems from SCHNEEBERGER are machine-compatible with integrated distance measuring systems in ready-to-install quality, suitable for a wide range of applications in mechanical engineering and automation. MONORAIL carriages are equipped as standard with twin-lipped cross wipers on the ends and top and bottom longitudinal wipers. Together with additional sealing of the gaps between the front plate and the steel body, these provide an exceptionally efficient sealing system. The ingress of dirt is therefore effectively prevented and lubrication losses are reduced to a minimum, which results in a significant increase in service life. The maximum one-piece profile rail length for all AMS distance measuring systems is 6 meters. For the analog…

The situation regarding the coronavirus has now worsened worldwide and is very dynamic. At SCHNEEBERGER all production areas are still running and deliveries are going out as confirmed by us to our customers. Thanks to our actively controlled supply chain network, we are still able to meet customer requirements on time. If this should change, you will of course be informed by us promptly. Make an appointment to discuss your request with us. We are certain that you will also find the right product with us. For more detailed information about  SCHNEEBERGER products, such as MONORAIL, ball screws, MINIRAIL, gear racks, measuring-, or positioning systems and how they are used, please contact your SCHNEEBERGER representative. Do not hesitate to contact us at any time for a no-obligation consultation. We look forward to hearing from you and working with you to develop the best solutions for you.

A.MANNESMANN, a global manufacturer of high-performance ball screws, has been part of the SCHNEEBERGER Group since October 2017. More than 50 years ago, A.MANNESMANN was one of the first manufacturers in Europe to introduce the ball screw and innovate the product while continually sharing knowledge and experience with market-leading operators. The company has consistently met the increasing demands of the technology required to compete. AM ball screws can be deployed over a variety of technical requirements. Traveling speeds ranging from virtually 0 m/min to 150 m/min, and accelerations of up to 20 m/sec² are easily achieved and A. MANNESAMANN ball screws are generally designed for an operating life of more than 20,000 hours! The constant torque, precise travel movements – even in reverse mode, along with positioning capability and repeatability are all standard features of AM ball screws. A.MANNESMANN is your single source provider of quality, innovative and cost competitive…

MONORAIL BZ is a compact, integrated assembly consisting of a 4-way ball guided profile rail guideway and a rack and pinion drive system. The combination of "guiding" and "drive" in one product offers the user the following advantages. The individual characteristic features of the two individual components are completely maintained. One-piece assembly lengths up to 6000 mm. The guideway component provides the best running properties, a high load-bearing capacity and service life in conjunction with a large number of carriage types, executions and accessories. The hardened and ground gearing of the drive component represents the highest quality and accuracy. Matching pinions are also available. The design effort is minimized compared to individual components, as the guideway, rack and pinion are already perfectly matched to each other. Compared to individual components, the required installation space is significantly smaller. This enables performance-optimized designs. The…

MONORAIL MR 4x roller-guided profile linear guideways are synonymous with maximum quality and guaranteed functionality. Outstanding degrees of rail straightness, accurate machining and high mechanical load capacity distinguish MONORAIL MR profile guideways as an efficient, extremely robust quality solution for demanding applications requiring the most stringent demands for accuracy, such as for tooling machines. The product portfolio is comprised of 23 different combinations of rail size and shape as well as 33 different carriage configurations, offering the greatest possible design flexibility. MONORAIL MR can optionally be equipped with a tried-and-tested, integrated distance measuring system, thus contributing significantly to the total cost of ownership (TCO). With experience gained from installing thousands of guideways in the field, we have given MONORAIL MR 4S carriages a comprehensive design upgrade and further improved the following four product features. Serviceability…

Die werotec ag mit Sitz in Reigoldswil (BL) wird per sofort 2020 mit der SCHNEEBERGER Firmengruppe mit Sitz in Roggwil (BE) verschmolzen Bereits Anfang 2018 wurden sämtliche Gesellschafteranteile an der werotec ag von der SCHNEEBERGER Firmengruppe übernommen. Die beiden führenden Unternehmen waren seit vielen Jahren erfolgreiche Geschäftspartner und ergänzten sich hervorragend mit ihren Komplementärprodukten. Die Übernahme stärkte beide Unternehmen und somit die Schweizer Maschinenindustrie. Mit der nunmehr per sofort vollzogenen Integration der werotec ag in die SCHNEEBERGER AG Lineartechnik stellt die SCHNEEBERGER-Gruppe die termingerechte Verfügbarkeit an Wälzkörpern auch bei wachsender Nachfrage in ausreichendem Volumen und in höchster Qualität sicher. Die werotec ag wird künftig als Geschäftsbereich der SCHNEEBERGER AG Lineartechnik geführt. Die Mitarbeitenden bleiben weiterhin am Standort Reigoldswil beschäftigt. Die bestehenden Vereinbarungen mit Lieferanten, Kunden und…

The standard length of a gear rack is usually 1000 mm. During assembly, these are installed one after the other. This inevitably leads to tolerances that are reflected in the form of a pitch error, which in turn leads to increased wear. With increasing axle length and the associated increasing number of gear racks to be installed, this error becomes even greater. Gear racks from SCHNEEBERGER, on the other hand, are available in lengths of up to 3000 mm (2000 mm for Q5). The main benefit is Fewer gear racks have to be installed per machine axis. This reduces installation time. By reducing the number of gear racks required, the pitch error is minimized, thus increasing the service life. Furthermore, SCHNEEBERGER gear racks feature the option of any desired cross-section with different types of attachments, entirely according to the customer's requirements. The excellent performance – and technical superiority – of SCHNEEBERGER gear racks are due to careful manufacturing, the…
